Show Color Variants On Collection Pages As Separate Product

Show Color Variants On Collection Pages As Separate Product

Compatibility: All Shopify 2.0 FREE themes ONLY. Works from lower version to version 12

When setting up an e-commerce store, it's important to provide your customers with a clear and comprehensive product page that showcases all available variants. However, sometimes a single product may have multiple variants that differ in color, design, or other features. You can easily separate each variant by its specific feature by using the code below.

If you do not want to separate the variants by color or any specific feature, you can use the product variant collection for all variants.

To implement the secondary image, we can modify your store's liquid code to include the secondary image in the product's HTML markup. This can be done using a conditional statement that checks whether the variant has a secondary image defined in its metafield. If it does, the code will generate an HTML element that displays the image on hover.

We use the following variant metafield below to show a secondary variant image.

Variant metafield



Additionally, you can check out our demo store, which showcases this feature in action. To access our demo store, please use the password 'made4uo'.

What are Show Color Variants On Collection Pages As Separate Product?

Refers to a Shopify code snippet that allows store owners to display each color variant of a product as a separate product on collection pages.

This means that instead of seeing a single product with a list of all the available colors, customers would see each color variant as its own individual product on the collection page. This can be helpful for customers because it makes it easier for them to find the specific variant they are looking for.

Why Use Show Color Variants On Collection Pages As Separate Product?

There are two main reasons why you might want to use the code snippet to show color variants on collection pages as separate products:

  • Improved product browsing: When browsing a collection of products, this can be helpful for customers because it makes it easier for them to see all of the different color options available for each product at a glance. They don't have to click on each individual product to see the available colors.

  • Increased visibility: By showing each variant as a separate product, it can increase the visibility of each color option in your collection. This can be especially beneficial if you have a large number of color variants for a particular product.

Additional Considerations:



  • You will need to provide featured images to the variants.
  • Use the metafield variant image to provide hover images.
  • You can choose which option you want to separate using the theme editor.
  • You can hide all variant titles or show only the color title.
  • There is an option to hide the "out of stock" variants, but the filter will only work with products and not variants.



What you are buying:

  • A collection of instead products, it will show product variants with color or type (depending on which option you want to show)
  • Will show the first second variant option, e.g. S for size option
  • You will need to provide featured images to the variants
  • Use metafield variant image to provide hover image
  • Assign which option you want to separate using the theme editor
  • Hide all variant title or show color title only
  • Option to hide the "out of stock" variants, not products
  • Filters works with products only therefore it will NOT filter by variant

What makes our code better:

  • We do not use external libraries, with that being said, our code will have no to minimal effect to your website's speed performance
  • We do not leave or add codes use to advertise for our website
  • Our code is mobile friendly

Any issues related to the code will be fix with no additional cost, excluding code customization requests. Simply contact us with "Chat with us." We are just a button away.

[]

Steps on how to add Show Color Variants On Collection Pages As Separate Product:

Step #1. Open your code editor

From you Admin page, go to Online store, then Themes. Choose the theme you want to edit, then click the three dots, then Edit code.

Step #2. Create a new section file

In Section folder, create a new section, name it collection-variant-color, then replace the default code with the code below.

{{ 'template-collection.css' | asset_url | stylesheet_tag }}
{{ 'component-loading-overlay.css' | asset_url | stylesheet_tag }}
{{ 'component-card.css' | asset_url | stylesheet_tag }}
{{ 'component-price.css' | asset_url | stylesheet_tag }}
{% if section.settings.image_shape == 'blob' %}
  {{ 'mask-blobs.css' | asset_url | stylesheet_tag }}
{%- endif -%}
{%- if section.settings.enable_quick_add -%}
  {{ 'quick-add.css' | asset_url | stylesheet_tag }}
  <script src="{{ 'quick-add.js' | asset_url }}" defer="defer"></script>
  <script src="{{ 'product-form.js' | asset_url }}" defer="defer"></script>
{%- endif -%}
{%- style -%}
  .section-{{ section.id }}-padding {
    padding-top: {{ section.settings.padding_top | times: 0.75 | round: 0 }}px;
    padding-bottom: {{ section.settings.padding_bottom | times: 0.75 | round: 0 }}px;
  }

  @media screen and (min-width: 750px) {
    .section-{{ section.id }}-padding {
      padding-top: {{ section.settings.padding_top }}px;
      padding-bottom: {{ section.settings.padding_bottom }}px;
    }
  }
{%- endstyle -%}
<div class="section-{{ section.id }}-padding">
  {%- paginate collection.products by section.settings.products_per_page -%}
    {% comment %} Sort is the first tabbable element when filter type is vertical {% endcomment %}
    {%- if section.settings.enable_sorting and section.settings.filter_type == 'vertical' -%}
      <facet-filters-form class="facets facets-vertical-sort page-width small-hide no-js-hidden">
        <form class="facets-vertical-form" id="FacetSortForm">
          <div class="facet-filters sorting caption">
            <div class="facet-filters__field">
              <h2 class="facet-filters__label caption-large text-body">
                <label for="SortBy">{{ 'products.facets.sort_by_label' | t }}</label>
              </h2>
              <div class="select">
                {%- assign sort_by = collection.sort_by | default: collection.default_sort_by -%}
                <select
                  name="sort_by"
                  class="facet-filters__sort select__select caption-large"
                  id="SortBy"
                  aria-describedby="a11y-refresh-page-message"
                >
                  {%- for option in collection.sort_options -%}
                    <option
                      value="{{ option.value | escape }}"
                      {% if option.value == sort_by %}
                        selected="selected"
                      {% endif %}
                    >
                      {{ option.name | escape }}
                    </option>
                  {%- endfor -%}
                </select>
                {% render 'icon-caret' %}
              </div>
            </div>
            <noscript>
              <button type="submit" class="facets__button-no-js button button--secondary">
                {{ 'products.facets.sort_button' | t }}
              </button>
            </noscript>
          </div>
          <div class="product-count-vertical light" role="status">
            <h2 class="product-count__text text-body">
              <span id="ProductCountDesktop">
                {%- if collection.results_count -%}
                  {{
                    'templates.search.results_with_count'
                    | t: terms: collection.terms, count: collection.results_count
                  }}
                {%- elsif collection.products_count == collection.all_products_count -%}
                  {{ 'products.facets.product_count_simple' | t: count: collection.products_count }}
                {%- else -%}
                  {{
                    'products.facets.product_count'
                    | t: product_count: collection.products_count, count: collection.all_products_count
                  }}
                {%- endif -%}
              </span>
            </h2>
            <div class="loading-overlay__spinner">
              <svg
                aria-hidden="true"
                focusable="false"
                class="spinner"
                viewBox="0 0 66 66"
                xmlns="http://www.w3.org/2000/svg"
              >
                <circle class="path" fill="none" stroke-width="6" cx="33" cy="33" r="30"></circle>
              </svg>
            </div>
          </div>
        </form>
      </facet-filters-form>
    {%- endif -%}
    <div class="{% if section.settings.filter_type == 'vertical' %} facets-vertical page-width{% endif %}">
      {{ 'component-facets.css' | asset_url | stylesheet_tag }}
      <script src="{{ 'facets.js' | asset_url }}" defer="defer"></script>
      {%- if section.settings.enable_filtering or section.settings.enable_sorting -%}
        <aside
          aria-labelledby="verticalTitle"
          class="facets-wrapper{% unless section.settings.enable_filtering %} facets-wrapper--no-filters{% endunless %}{% if section.settings.filter_type != 'vertical' %} page-width{% endif %}"
          id="main-collection-filters"
          data-id="{{ section.id }}"
        >
          {% render 'facets',
            results: collection,
            enable_filtering: section.settings.enable_filtering,
            enable_sorting: section.settings.enable_sorting,
            filter_type: section.settings.filter_type,
            paginate: paginate
          %}
        </aside>
      {%- endif -%}
      <div
        class="product-grid-container{% if settings.animations_reveal_on_scroll %} scroll-trigger animate--slide-in{% endif %}"
        id="ProductGridContainer"
        {% if settings.animations_reveal_on_scroll %}
          data-cascade
        {% endif %}
      >
        {%- if collection.products.size == 0 -%}
          <div class="collection collection--empty page-width" id="product-grid" data-id="{{ section.id }}">
            <div class="loading-overlay gradient"></div>
            <div class="title-wrapper center">
              <h2 class="title title--primary">
                {{ 'sections.collection_template.empty' | t -}}
                <br>
                {{
                  'sections.collection_template.use_fewer_filters_html'
                  | t: link: collection.url, class: 'underlined-link link'
                }}
              </h2>
            </div>
          </div>
        {%- else -%}
          <div class="collection{% if section.settings.filter_type != 'vertical' %} page-width{% endif %}">
            <div class="loading-overlay gradient"></div>
            <ul
              id="product-grid"
              data-id="{{ section.id }}"
              class="
                grid product-grid grid--{{ section.settings.columns_mobile }}-col-tablet-down
                grid--{{ section.settings.columns_desktop }}-col-desktop
              "
            >
              {%- for product in collection.products -%}
                {% assign lazy_load = false %}
                {%- if forloop.index > 2 -%}
                  {%- assign lazy_load = true -%}
                {%- endif -%}

                {% assign color = '' %}
                {% assign variant_color = '' %}
                {% assign optionColor = section.settings.optionColor %}

                {% for variant in product.variants %}
                  {% case optionColor %}
                    {% when '1' %}
                      {% assign variant_color = variant.option1 %}
                    {% when '2' %}
                      {% assign variant_color = variant.option2 %}
                    {% when '3' %}
                      {% assign variant_color = variant.option3 %}
                  {% endcase %}
                  {%- if variant_color != color -%}
                    <li
                      class="grid__item{% if settings.animations_reveal_on_scroll %} scroll-trigger animate--slide-in{% endif %}"
                      {% if settings.animations_reveal_on_scroll %}
                        data-cascade
                        style="--animation-order: {{ forloop.index }};"
                      {% endif %}
                    >
                      {% render 'variant-card',
                        card_product: product,
                        card_variant: variant,
                        image_shape: section.settings.image_shape,
                        show_secondary_image: section.settings.show_secondary_image,
                        media_aspect_ratio: section.settings.image_ratio,
                        show_vendor: section.settings.show_vendor,
                        show_rating: section.settings.show_rating,
                        lazy_load: lazy_load,
                        show_quick_add: section.settings.enable_quick_add,
                        section_id: section.id,
                        hide_variant_info: section.settings.hide_variant_info,
                        option: optionColor
                      %}
                    </li>
                    {% assign color = variant_color %}
                  {% endif %}
                {% endfor %}
              {%- endfor -%}
            </ul>
            {%- if paginate.pages > 1 -%}
              {% render 'pagination', paginate: paginate, anchor: '' %}
            {%- endif -%}
          </div>
        {%- endif -%}
      </div>
    </div>
  {%- endpaginate -%}
  {% if section.settings.image_shape == 'arch' %}
    {% render 'mask-arch' %}
  {%- endif -%}
</div>
{% schema %}
{
  "name": "t:sections.main-collection-product-grid.name",
  "class": "section",
  "settings": [
    {
      "type": "range",
      "id": "products_per_page",
      "min": 8,
      "max": 24,
      "step": 4,
      "default": 16,
      "label": "t:sections.main-collection-product-grid.settings.products_per_page.label"
    },
    {
      "type": "range",
      "id": "columns_desktop",
      "min": 1,
      "max": 5,
      "step": 1,
      "default": 4,
      "label": "t:sections.main-collection-product-grid.settings.columns_desktop.label"
    },
    {
      "type": "select",
      "id": "optionColor",
      "options": [
        {
          "value": "1",
          "label": "First option"
        },
        {
          "value": "2",
          "label": "Second option"
        },
        {
          "value": "3",
          "label": "Third option"
        }
      ],
      "default": "1",
      "label": "Color option placement",
      "info": "Choose which option is the color"
    },
    {
      "type": "header",
      "content": "t:sections.main-collection-product-grid.settings.header__3.content"
    },
    {
      "type": "select",
      "id": "image_ratio",
      "options": [
        {
          "value": "adapt",
          "label": "t:sections.main-collection-product-grid.settings.image_ratio.options__1.label"
        },
        {
          "value": "portrait",
          "label": "t:sections.main-collection-product-grid.settings.image_ratio.options__2.label"
        },
        {
          "value": "square",
          "label": "t:sections.main-collection-product-grid.settings.image_ratio.options__3.label"
        }
      ],
      "default": "adapt",
      "label": "t:sections.main-collection-product-grid.settings.image_ratio.label"
    },
    {
      "type": "select",
      "id": "image_shape",
      "options": [
        {
          "value": "default",
          "label": "t:sections.all.image_shape.options__1.label"
        },
        {
          "value": "arch",
          "label": "t:sections.all.image_shape.options__2.label"
        },
        {
          "value": "blob",
          "label": "t:sections.all.image_shape.options__3.label"
        },
        {
          "value": "chevronleft",
          "label": "t:sections.all.image_shape.options__4.label"
        },
        {
          "value": "chevronright",
          "label": "t:sections.all.image_shape.options__5.label"
        },
        {
          "value": "diamond",
          "label": "t:sections.all.image_shape.options__6.label"
        },
        {
          "value": "parallelogram",
          "label": "t:sections.all.image_shape.options__7.label"
        },
        {
          "value": "round",
          "label": "t:sections.all.image_shape.options__8.label"
        }
      ],
      "default": "default",
      "label": "t:sections.all.image_shape.label",
      "info": "t:sections.all.image_shape.info"
    },
    {
      "type": "checkbox",
      "id": "hide_variant_info",
      "default": false,
      "label": "Hide the variant title"
    },
    {
      "type": "checkbox",
      "id": "show_secondary_image",
      "default": false,
      "info": "You must add the variant metafield",
      "label": "t:sections.main-collection-product-grid.settings.show_secondary_image.label"
    },
    {
      "type": "checkbox",
      "id": "show_vendor",
      "default": false,
      "label": "t:sections.main-collection-product-grid.settings.show_vendor.label"
    },
    {
      "type": "checkbox",
      "id": "show_rating",
      "default": false,
      "label": "t:sections.main-collection-product-grid.settings.show_rating.label",
      "info": "t:sections.main-collection-product-grid.settings.show_rating.info"
    },
    {
      "type": "checkbox",
      "id": "enable_quick_add",
      "default": false,
      "label": "t:sections.main-collection-product-grid.settings.enable_quick_buy.label"
    },
    {
      "type": "header",
      "content": "t:sections.main-collection-product-grid.settings.header__1.content"
    },
    {
      "type": "checkbox",
      "id": "enable_filtering",
      "default": true,
      "label": "t:sections.main-collection-product-grid.settings.enable_filtering.label",
      "info": "t:sections.main-collection-product-grid.settings.enable_filtering.info"
    },
    {
      "type": "select",
      "id": "filter_type",
      "options": [
        {
          "value": "horizontal",
          "label": "t:sections.main-collection-product-grid.settings.filter_type.options__1.label"
        },
        {
          "value": "vertical",
          "label": "t:sections.main-collection-product-grid.settings.filter_type.options__2.label"
        },
        {
          "value": "drawer",
          "label": "t:sections.main-collection-product-grid.settings.filter_type.options__3.label"
        }
      ],
      "default": "horizontal",
      "label": "t:sections.main-collection-product-grid.settings.filter_type.label",
      "info": "t:sections.main-collection-product-grid.settings.filter_type.info"
    },
    {
      "type": "checkbox",
      "id": "enable_sorting",
      "default": true,
      "label": "t:sections.main-collection-product-grid.settings.enable_sorting.label"
    },
    {
      "type": "header",
      "content": "t:sections.main-collection-product-grid.settings.header_mobile.content"
    },
    {
      "type": "select",
      "id": "columns_mobile",
      "default": "2",
      "label": "t:sections.main-collection-product-grid.settings.columns_mobile.label",
      "options": [
        {
          "value": "1",
          "label": "t:sections.main-collection-product-grid.settings.columns_mobile.options__1.label"
        },
        {
          "value": "2",
          "label": "t:sections.main-collection-product-grid.settings.columns_mobile.options__2.label"
        }
      ]
    },
    {
      "type": "header",
      "content": "t:sections.all.padding.section_padding_heading"
    },
    {
      "type": "range",
      "id": "padding_top",
      "min": 0,
      "max": 100,
      "step": 4,
      "unit": "px",
      "label": "t:sections.all.padding.padding_top",
      "default": 36
    },
    {
      "type": "range",
      "id": "padding_bottom",
      "min": 0,
      "max": 100,
      "step": 4,
      "unit": "px",
      "label": "t:sections.all.padding.padding_bottom",
      "default": 36
    }
  ]
}
{% endschema %}




Step #3. Follow the video or create New Collection Template

If you want  to assign this collection template as a default, then follow the video.

If not, we need to create a new collection template. Open and copy the code in the "collection.json" under the Template folder. Then paste the code to the newly created template.

Inside the newly created template, find this code "main-collection-product-grid" and replace with the name "collection-variant color".

Step #4. Make a code snippet

We need to make a code snippet. Go to Snippet folder, create a new snippet, name it variant-card.

Step #3. Paste the code

Paste the code below to the newly created snippet. Make sure to SAVE.

{% comment %}
  Renders a product card
  Accepts:
  - card_product: {Object} Product Liquid object (optional)
  - media_aspect_ratio: {String} Size of the product image card. Values are "square" and "portrait". Default is "square" (optional)
  - show_secondary_image: {Boolean} Show the secondary image on hover. Default: false (optional)
  - show_vendor: {Boolean} Show the product vendor. Default: false
  - show_rating: {Boolean} Show the product rating. Default: false
  - extend_height: {Boolean} Card height extends to available container space. Default: true (optional)
  - lazy_load: {Boolean} Image should be lazy loaded. Default: true (optional)
  - show_quick_add: {Boolean} Show the quick add button.
  - section_id: {String} The ID of the section that contains this card.
  - option: number
  - hide_variant_info: {Boolean} Show variant color title
  Usage:
  {% render 'variant-card', show_vendor: section.settings.show_vendor %}
{% endcomment %}
{{ 'component-rating.css' | asset_url | stylesheet_tag }}
{{ 'component-volume-pricing.css' | asset_url | stylesheet_tag }}
{%- if card_variant and card_variant != empty -%}
  {%- liquid
    assign ratio = 1
    if card_variant.featured_media and media_aspect_ratio == 'portrait'
      assign ratio = 0.8
    elsif card_variant.featured_media and media_aspect_ratio == 'adapt'
      assign ratio = card_variant.featured_media.aspect_ratio
    endif
    if ratio == 0 or ratio == null
      assign ratio = 1
    endif
  -%}
  <div class="card-wrapper product-card-wrapper underline-links-hover">
    <div
      class="
        card
        card--{{ settings.card_style }}
        {% if card_variant.featured_media %} card--media{% else %} card--text{% endif %}
        {% if settings.card_style == 'card' %} color-{{ settings.card_color_scheme }} gradient{% endif %}
        {% if extend_height %} card--extend-height{% endif %}
        {% if card_variant.featured_media == nil and settings.card_style == 'card' %} ratio{% endif %}
        {% if horizontal_class %} card--horizontal{% endif %}
      "
      style="--ratio-percent: {{ 1 | divided_by: ratio | times: 100 }}%;"
    >
      <div
        class="card__inner {% if settings.card_style == 'standard' %}color-{{ settings.card_color_scheme }} gradient{% endif %}{% if card_product.featured_media or settings.card_style == 'standard' %} ratio{% endif %}"
        style="--ratio-percent: {{ 1 | divided_by: ratio | times: 100 }}%;"
      >
        {%- if card_variant.featured_media -%}
          <div class="card__media{% if image_shape and image_shape != 'default' %} shape--{{ image_shape }} color-{{ settings.card_color_scheme }} gradient{% endif %}">
            <div class="media media--transparent media--hover-effect">
              {% comment %}theme-check-disable ImgLazyLoading{% endcomment %}
              <img
                srcset="
                  {%- if card_variant.featured_media.width >= 165 -%}{{ card_variant.featured_media | image_url: width: 165 }} 165w,{%- endif -%}
                  {%- if card_variant.featured_media.width >= 360 -%}{{ card_variant.featured_media | image_url: width: 360 }} 360w,{%- endif -%}
                  {%- if card_variant.featured_media.width >= 533 -%}{{ card_variant.featured_media | image_url: width: 533 }} 533w,{%- endif -%}
                  {%- if card_variant.featured_media.width >= 720 -%}{{ card_variant.featured_media | image_url: width: 720 }} 720w,{%- endif -%}
                  {%- if card_variant.featured_media.width >= 940 -%}{{ card_variant.featured_media | image_url: width: 940 }} 940w,{%- endif -%}
                  {%- if card_variant.featured_media.width >= 1066 -%}{{ card_variant.featured_media | image_url: width: 1066 }} 1066w,{%- endif -%}
                  {{ card_variant.featured_media | image_url }} {{ card_variant.featured_media.width }}w
                "
                src="{{ card_variant.featured_media | image_url: width: 533 }}"
                sizes="(min-width: {{ settings.page_width }}px) {{ settings.page_width | minus: 130 | divided_by: 4 }}px, (min-width: 990px) calc((100vw - 130px) / 4), (min-width: 750px) calc((100vw - 120px) / 3), calc((100vw - 35px) / 2)"
                alt="{{ card_variant.featured_media.alt | escape }}"
                class="motion-reduce"
                {% unless lazy_load == false %}
                  loading="lazy"
                {% endunless %}
                width="{{ card_variant.featured_media.width }}"
                height="{{ card_variant.featured_media.height }}"
              >
              {% comment %}theme-check-enable ImgLazyLoading{% endcomment %}

              {% assign meta_image = card_variant.metafields.my_fields['secondary-image'] %}
              {% if meta_image != null and show_secondary_image %}
                <img
                  src="{{ meta_image | image_url: width: 533 }}"
                  sizes="(min-width: {{ settings.page_width }}px) {{ settings.page_width | minus: 130 | divided_by: 4 }}px, (min-width: 990px) calc((100vw - 130px) / 4), (min-width: 750px) calc((100vw - 120px) / 3), calc((100vw - 35px) / 2)"
                  alt="{{ meta_image.alt | escape }}"
                  class="motion-reduce"
                  loading="lazy"
                  width="{{ meta_image.width }}"
                  height="{{ meta_image.height }}"
                >
              {% endif %}
            </div>
          </div>
        {%- endif -%}
      </div>
      <div class="card__content">
        <div class="card__information">
          <h3
            class="card__heading{% if card_variant.featured_media or settings.card_style == 'standard' %} h5{% endif %}"
            {% if card_variant.featured_media or settings.card_style == 'card' %}
              id="title-{{ section_id }}-{{ card_product.id }}"
            {% endif %}
          >
            <a href="{{ card_variant.url }}" class="full-unstyled-link">
              {{ card_product.title | escape }}
              {% if hide_variant_info == false %}
                <br>
                {% assign variantTitle = card_variant.title | split: '/' %}
                {% if option == '1' %}
                  {{ variantTitle[0] }}
                {% elsif option == '2' %}
                  {{ variantTitle[1] }}
                {% elsif option == '3' %}
                  {{ variantTitle[2] }}
                {% endif %}
              {% endif %}
            </a>
          </h3>
          <div class="card-information">
            {%- if show_vendor -%}
              <span class="visually-hidden">{{ 'accessibility.vendor' | t }}</span>
              <div class="caption-with-letter-spacing light">{{ card_product.vendor }}</div>
            {%- endif -%}
            <span class="caption-large light">{{ block.settings.description | escape }}</span>
            {%- if show_rating and card_product.metafields.reviews.rating.value != blank -%}
              {% liquid
                assign rating_decimal = 0
                assign decimal = card_product.metafields.reviews.rating.value.rating | modulo: 1
                if decimal >= 0.3 and decimal <= 0.7
                  assign rating_decimal = 0.5
                elsif decimal > 0.7
                  assign rating_decimal = 1
                endif
              %}
              <div
                class="rating"
                role="img"
                aria-label="{{ 'accessibility.star_reviews_info' | t: rating_value: card_product.metafields.reviews.rating.value, rating_max: card_product.metafields.reviews.rating.value.scale_max }}"
              >
                <span
                  aria-hidden="true"
                  class="rating-star color-icon-{{ settings.accent_icons }}"
                  style="--rating: {{ card_product.metafields.reviews.rating.value.rating | floor }}; --rating-max: {{ card_product.metafields.reviews.rating.value.scale_max }}; --rating-decimal: {{ rating_decimal }};"
                ></span>
              </div>
              <p class="rating-text caption">
                <span aria-hidden="true">
                  {{- card_product.metafields.reviews.rating.value }} /
                  {{ card_product.metafields.reviews.rating.value.scale_max -}}
                </span>
              </p>
              <p class="rating-count caption">
                <span aria-hidden="true">({{ card_product.metafields.reviews.rating_count }})</span>
                <span class="visually-hidden">
                  {{- card_product.metafields.reviews.rating_count }}
                  {{ 'accessibility.total_reviews' | t -}}
                </span>
              </p>
            {%- endif -%}
            {% render 'price', product: card_variant, price_class: '' %}
          </div>
        </div>
        {%- if show_quick_add -%}
          <div class="quick-add">
            {%- assign product_form_id = 'quick-add-' | append: section_id | append: card_variant.id -%}
            {%- if card_product.has_only_default_variant -%}
              <product-form>
                {%- form 'product',
                  card_variant,
                  id: product_form_id,
                  class: 'form',
                  novalidate: 'novalidate',
                  data-type: 'add-to-cart-form'
                -%}
                  <input
                    type="hidden"
                    name="id"
                    value="{{ card_variant.selected_or_first_available_variant.id }}"
                    disabled
                  >
                  <button
                    id="{{ product_form_id }}-submit"
                    type="submit"
                    name="add"
                    class="quick-add__submit button button--full-width button--secondary"
                    aria-haspopup="dialog"
                    aria-labelledby="{{ product_form_id }}-submit title-{{ section_id }}-{{ card_variant.id }}"
                    aria-live="polite"
                    data-sold-out-message="true"
                    {% if card_variant.selected_or_first_available_variant.available == false %}
                      disabled
                    {% endif %}
                  >
                    <span>
                      {%- if card_variant.selected_or_first_available_variant.available -%}
                        {{ 'products.product.add_to_cart' | t }}
                      {%- else -%}
                        {{ 'products.product.sold_out' | t }}
                      {%- endif -%}
                    </span>
                    <span class="sold-out-message hidden">
                      {{ 'products.product.sold_out' | t }}
                    </span>
                    <div class="loading-overlay__spinner hidden">
                      <svg
                        aria-hidden="true"
                        focusable="false"
                        role="presentation"
                        class="spinner"
                        viewBox="0 0 66 66"
                        xmlns="http://www.w3.org/2000/svg"
                      >
                        <circle class="path" fill="none" stroke-width="6" cx="33" cy="33" r="30"></circle>
                      </svg>
                    </div>
                  </button>
                {%- endform -%}
              </product-form>
            {%- else -%}
              <modal-opener data-modal="#QuickAdd-{{ card_product.id }}">
                <button
                  id="{{ product_form_id }}-submit"
                  type="submit"
                  name="add"
                  class="quick-add__submit button button--full-width button--secondary"
                  aria-haspopup="dialog"
                  aria-labelledby="{{ product_form_id }}-submit title-{{ section_id }}-{{ card_product.id }}"
                  data-product-url="{{ card_product.url }}"
                >
                  {{ 'products.product.choose_options' | t }}
                  <div class="loading-overlay__spinner hidden">
                    <svg
                      aria-hidden="true"
                      focusable="false"
                      role="presentation"
                      class="spinner"
                      viewBox="0 0 66 66"
                      xmlns="http://www.w3.org/2000/svg"
                    >
                      <circle class="path" fill="none" stroke-width="6" cx="33" cy="33" r="30"></circle>
                    </svg>
                  </div>
                </button>
              </modal-opener>
              <quick-add-modal id="QuickAdd-{{ card_product.id }}" class="quick-add-modal">
                <div
                  role="dialog"
                  aria-label="{{ 'products.product.choose_product_options' | t: product_name: card_product.title | escape }}"
                  aria-modal="true"
                  class="quick-add-modal__content global-settings-popup"
                  tabindex="-1"
                >
                  <button
                    id="ModalClose-{{ card_product.id }}"
                    type="button"
                    class="quick-add-modal__toggle"
                    aria-label="{{ 'accessibility.close' | t }}"
                  >
                    {% render 'icon-close' %}
                  </button>
                  <div id="QuickAddInfo-{{ card_product.id }}" class="quick-add-modal__content-info"></div>
                </div>
              </quick-add-modal>
            {%- endif -%}
          </div>
        {%- endif -%}
        <div class="card__badge {{ settings.badge_position }}">
          {%- if card_variant.available == false -%}
            <span class="badge badge--bottom-left color-{{ settings.sold_out_badge_color_scheme }}">
              {{- 'products.product.sold_out' | t -}}
            </span>
          {%- elsif card_variant.compare_at_price > card_variant.price and card_variant.available -%}
            <span class="badge badge--bottom-left color-{{ settings.sale_badge_color_scheme }}">
              {{- 'products.product.on_sale' | t -}}
            </span>
          {%- endif -%}
        </div>
      </div>
    </div>
  </div>
{%- else -%}
  <div class="card-wrapper underline-links-hover">
    <div
      class="
        card
        card--{{ settings.card_style }}
        card--text
        {% if extend_height %} card--extend-height{% endif %}
        {% if settings.card_style == 'card' %} color-{{ settings.card_color_scheme }} gradient{% endif %}
        {% if card_variant.featured_media == nil and settings.card_style == 'card' %} ratio{% endif %}
      "
      style="--ratio-percent: 100%;"
    >
      <div
        class="card__inner {% if settings.card_style == 'standard' %}color-{{ settings.card_color_scheme }} gradient{% endif %}{% if settings.card_style == 'standard' %} ratio{% endif %}"
        style="--ratio-percent: 100%;"
      >
        <div class="card__content">
          <div class="card__information">
            <h3 class="card__heading">
              <a role="link" aria-disabled="true" class="full-unstyled-link">
                {{ 'onboarding.product_title' | t }}
              </a>
            </h3>
          </div>
        </div>
      </div>
      <div class="card__content">
        <div class="card__information">
          <h3 class="card__heading{% if settings.card_style == 'standard' %} h5{% endif %}">
            <a role="link" aria-disabled="true" class="full-unstyled-link">
              {{ 'onboarding.product_title' | t }}
            </a>
          </h3>
          <div class="card-information">
            {%- if show_vendor -%}
              <span class="visually-hidden">{{ 'accessibility.vendor' | t }}</span>
              <div class="caption-with-letter-spacing light">{{ 'products.product.vendor' | t }}</div>
            {%- endif -%}
            {% render 'price' %}
          </div>
        </div>
      </div>
    </div>
  </div>
{%- endif -%}

Step #4. Customize theme

Go to the theme editor by clicking three dots on your left hand upper corner, then Customize theme. Add a section named "Image side by side". Make sure to SAVE once you are done customizing.

Conclusion

Shopify code snippet that allows you to display color variants of products on collection pages, presenting each variant as a separate product. This can improve product browsing for customers and increase the visibility of your color options.

4 comments

Hi SHAYLA,
We updated the product into version 12.Please, check it again. Thanks!

Made4Uo •

Will this be updated for Dawn v12.0?

Shayla •

Hi,

We can do the installation for you with no extra cost. Just message us using “Chat with us” before purchasing.

Made4Uo •

can someone reach out about help us install this as well?

kelsey •

Leave a comment
